Custom made Security Window Screens

316 Marine Grade Stainless Steel Mesh

Custom made Defendoor security screen made to your exact specifications.

With 316 marine grade stainless steel mesh secured into a heavy-duty aluminium frame containing an internal vertical which will collapse upon impact causing a dramatic wedging action between the frame and security mesh. This technology has exceeded the Australian standard for impact testing along with knife sheer, and longevity tests.

Seconline security screens are available in a choice of 18 frame colours with black powder coated 316 Marine Grade Stainless Steel mesh.

 Please view all videos and read all information before proceeding with your order.

YOU MUST MAKE YOUR OWN DEDUCTIONS - See the DIY Info Centre

  The sizes you provide will be the exact size we make your window screen; if you are unsure please ask 1300 735 405.

 Security Window Grilles - 316 Marine Grade Stainless Steel Mesh

  • Custom made
  • 316 Marine Grade Stainless Steel mesh
  • Heavy duty extruded frames
  • Patented vertical leg - dramatic wedging action upon impact
  • Mesh powder coated black to replicate fly screen look
  • 18 standard frame colour choices
  • Custom frame colour option available
  • Frame size: 11 mm x 52 mm.
  • 9 mm frames can be made available at additional cost; please contact our Sales Team for a quote.





MESH - Woven steel powder coated black

Our 316 marine grade stainless steel mesh is extensively tested for dynamic impact, knife shear, salt spray, hinge and lever tests by an independent NATA accredited facility and also meets the requirements for construction in bush fire prone areas.

Stainless Steel Mesh

  • 1.1 x 1.1 x 0.80 mm
  • 316 Marine Grade Stainless Steel
  • Ultimate Tensile Strength 1060 Mpa
  • Higher Ni Content
  • Extensively tested for dynamic impact, knife shear and salt spray.
  • 5 year warranty on stainless steel mesh*

*Installed by licensed installer and proper maintenance schedule adhered to.

Note: Fitting screws not included.

SAFE AND SECURE

The Defendoor security system has been researched, designed and developed to set a new standard in security doors and windows.

FRAME

With advanced engineering technology researchers have achieve a frame incorporating a unique and stylish bull nose design that also exceeds all relevant Australian Standards. The Defendoor security system heavy-duty aluminium frame contains an internal vertical which will collapse upon impact causing a dramatic wedging action between the frame and security mesh.

FRAME SIZE: 11 mm x 52 mm

  • 9 mm frames can be made available at additional cost; please contact our Sales Team for a quote.



FRAME COLOURS



MESH SELECTION

316 marine grade stainless steel mesh – always refer to maintenance chart below or on our FAQ page when deciding on the type of mesh that is best suited for your location and environmental circumstances. Correct mesh selection and regular maintenance will keep your Seconline Security doors and windows looking good for years to come. In addition to this, our 316 stainless steel mesh is covered by a 5 year limited warranty.

PRODUCT SELECTION

Whilst it is the customers responsibility to select the correct mesh to suit their specific location and environment factors, authorised dealers will always refer their customers to the Product Selection and Maintenance Chart located on below or our FAQ page and advise that if the mesh wash is not used as part of the maintenance schedule, then the warranty will become void.

MAXIMUM CORROSION PROTECTION

When two dissimilar materials are used in contact with one another, a galvanic reaction can occur, causing corrosion. Defendoor has been designed to help eliminate contact between dissimilar metals by;

  • An easily inserted locking block to secure  the mesh sheeting to the aluminium frame, eliminating the need for crimping, screwing or clamping
  • Using an inhibiting tape to separate the mesh from the aluminium frame.
  • Powder coating the frame, mesh and locks. Mesh ash reduces corrosion and enhance the life of your Defendoor products.

Making doors is our passion and our customers love us.

If you have any questions feel free to chat to us.

1. How to measure an existing screen:

If you have existing screens and they are a good fit, then the easiest way to measure for new ones is to remeasure your old ones, ensure that you measure the recess width and advise us if it varies from the industry standard width of 11 mm.

Note: Do not take measurements from the centre in case the screen is bowed.

Screen Width: Measure from the outer edge of the frame top and bottom, record the smallest measurement. Note: There should be maximum of 3 mm variation in the two lengths, if the variation is greater contact us to discuss solutions 1300 735 405.

Screen Height: Measure the height left and right, record the smallest measurement.

Recess Width: Using a solid ruler measure the width of your recess, advise us when placing your order if your recess width is other than 11 mm.



2. How to measure for a new screen (face fixed):

Note: The safest method of measuring is to fit the screen to the face of the window and this is sometimes the only option. You would then drill through the frame of the window surround, and screw or rivet in place.

Screen Width: Measure the recess top and bottom, record the smallest measurement.

Screen Height: Measure the height left and right, record the smallest measurement.



3. How to measure for a new screen (recess fixed) 1.1

Screen Width: Measure inside recess of windows where screen will be located, top and bottom then deduct 2-3 mm to allow fitting clearance and record the smallest measurement.

Screen Height: Measure inside recess of windows where screen will be located, left and right then deduct 2-3 mm to allow fitting clearance and record the smallest measurement.

Recess Width: Using a solid ruler measure the width of your recess, advise us when placing your order if your recess width is other than 11 mm.

Recess Depth: Using a solid ruler measure the depth of your recess, advise us when placing your order if your recess depth is other than 11 mm.

1.1



Pop Rivet Face Fix:

Use a 3mm drill bit to pre-drill the holes then use 3mm x 15mm rivets to face fix the screens to the outside of the window frame.

Rivets should be placed 50mm away from each corner and space at least 30mm apart.
Pop Rivet Recess Fix:
Fit the screen into the recess, use a 3mm drill bit to pre-drill the holes, then use 3mm x 15mm through the recess and the window screen to fix into place.

Pop Rivet Face Fix:

Use a 3mm drill bit to pre-drill the holes then use 3mm x 15mm rivets to face fix the screens to the outside of the window frame.

Rivets should be placed 50mm away from each corner and space at least 30mm apart.
Pop Rivet Recess Fix:
Fit the screen into the recess, use a 3mm drill bit to pre-drill the holes, then use 3mm x 15mm through the recess and the window screen to fix into place.

Q. Where do I measure for my window grilles?

A. Before you measure you need to establish where exactly how you are going to fix the grille to the window. There are two basic types of external fixing.

Recess fix: Our standard window grille frame is 11 mm thick at the outer wall. This is so they may be fitted into the same recess on a window as a fly screen. They can then be fixed in place by riveting or screwing to the window recess either internally or externally. As there are a large variety of window extrusions a decision has to be made by the person installing the screen.

Face fix: When there is no recessed area provided for a fly screen the grille is simply fitted to the face of the window frame either internally or externally by drilling through the frame of the window surround, and screwing or riveting in place. Great care must be given to not interfere with the operation of the window's action, E.g. Window spirals etc.

Measuring for a recess fix is difficult due to the many variations in styles. The simplest method is to remeasure the existing fly screen if it is a good fit, and a fix can be obtained. If this option is not available then you must be mindful of being able to fit the screen into the recess whilst still covering the window. Remember: Fly screens are flexible, security window screens are not.

Q. What colours do you have as standard?

A. Seconline's security screens are available in 18 standard colours. Refer to Product Details for our full colour chart.

Q. Can I have another colour if I am happy to pay extra?

A. Yes. Please email with sizes and quantities and we will provide a quote including powder coating.

The video below features the the window grille frame.





Once your order is custom made to your specifications it is then packaged for shipment direct to your requested shipping address via Regional Road Express. Once dispatched you will be sent a connote number; see our Terms and Conditions page for estimated transit times.

From the time you place the order your item will be dispatched from our workshop within 10 to 15 working days*. Expected delivery time from date of order is five to ten working days, any delays due to Regional Road Express delivery will be communicated to you by our staff.

If you encounter any issues or have any questions during the ordering process please phone us on 1300 735 405, we are always happy to help.

* Pending availability of stock (Seconline will advise of any stock shortages that may extend the manufacturing time).
