Seconline Custom Made Fly Screens Midge Mesh



In addition to standard fiberglass and stainless steel fly mesh Seconline now stock midge mesh! For protection against sand flies; it is available for fly screens, 7 mm diamond doors and 7mm diamond window screens. It is black in colour and similar to standard fly mesh only has much smaller holes.

FRAME

  • Frame size: 11 mm x 25 mm extruded fly frame (not roll formed)
  • Horizontal centre strength bar on all screens
  • 14 standard colour choices. See Colour chart below.
  • Maximum width 1200 mm Maximum height 2000 mm
  • For over-sized screens send us a quote request info@seconline.com.au
  • 9 mm frames can be made available at additional cost; please contact our Sales Team for a quote.



 ***IMPORTANT - MEASURE YOUR RECESS BEFORE YOU ORDER!***

11 mm frames only fit recesses wider than 11 mm, Seconline will not replace screens ordered with the incorrect frame as they must be completely remade with all new stock.

 Please view all videos and read all information before proceeding with your order.

YOU MUST MAKE YOUR OWN DEDUCTIONS - See the DIY Info Centre

 The sizes you provide will be the exact size we make your fly screen; if you are unsure please ask 1300 735 405.



MESH

  • Available in: Black/Charcoal
  • Mesh: 20 x 20 per inch
  • Strand Diameter: 0.33mm
  • PVC Coated Fibreglass



FRAME: 11 mm x 25 mm



Frames available in a selection of 14 colours



Additional Items

  • 11 mm PVC turnbuckles - for face fixed fly screens
  • Plunger Pins - for recess fixed installation
  • Need Stainless Steel Fly Mesh? Contact us for a quote info@seconline.com.au

Looking for security screens? Check out our range of Defendoor Security Window Screens.

Making screens online is our passion and our customers love us!

If you have any questions feel free to chat to us.

 ***IMPORTANT - MEASURE YOUR RECESS BEFORE YOU ORDER!***

11 mm frames only fit recesses wider than 11 mm, Seconline will not replace screens ordered with the incorrect frame as they must be completely remade with all new stock.



Face Fixed: fitted to the face of the timber window sill; generally with 11mm PVC turnbuckles - available as an Add On when purchasing your screen.

Recess Fix: fitted into the recess provided by the window extrusion. These come to accommodate two types of flyscreen frames thicknesses; 11 mm (which is the most common) and 9 mm. Our flyscreens are industry standard 11 mm thick. If your window recess is 9mm we can accommodate this you must advise us of the recess width when placing your order.

Seconline also install spinger clips into our fly screen where requested. These can be purchased as an add on when purchasing your screen and  are fitted to the screens at the time of manufacture.


Method

MEASURING AN EXISTING SCREEN

Notes:

  • Do not take measurements from the centre in case the frame is bowed.
  • There should be maximum of 3 mm variation in the two lengths, if the variation is greater contact us to discuss solutions 1300 735 405.

Height: Measure the height left and right, record the shortest measurement.

Width: Measure from the outer edge of the frame top and bottom, record the shortest measurement.



MEASURING FOR A NEW SCREEN - FACE FIXED

Height: Measure the recess height left and right, record the shortest measurement.

Width: Measure the recess top and bottom, record the shortest measurement.



MEASURING FOR A NEW SCREEN - RECESS FIXED



Height: Not always, however in most cases the height recess at the bottom will be smaller in depth than the top.

  • Measure from Point A; which is the top of the bottom recess to Point B; which is the inside top of the the top recess.
  • Deduct 2 mm and this will be your height measurement.
  • The 2 mm is to allow the screen clearance when fitting.



Width: Again there will be variances in the depths of the recesses for different window manufacturers.

  • Measure from the lip of the shortest side, Point A, to the inside depth of Point B.
  • Deduct 2 mm and this will be your width measurement.
  • The 2 mm is to allow the screen clearance when fitting.

 ***IMPORTANT - MEASURE YOUR RECESS BEFORE YOU ORDER!***

11 mm frames only fit recesses wider than 11 mm, Seconline will not replace screens ordered with the incorrect frame as they must be completely remade with all new stock.

 Please view all videos and read all information before proceeding with your order.

YOU MUST MAKE YOUR OWN DEDUCTIONS - See the DIY Info Centre

 The sizes you provide will be the exact size we make your fly screen; if you are unsure please ask 1300 735 405.

  1. Where do I measure for my fly screens?
  2. Before you measure you need to establish where exactly how you are going to fix the fly screen to the window. There are two basic types of external fixing.

Recess fix: Our standard fly screen frame is 11 mm thick at the outer wall. Fixing can be by riveting or screwing either internally or externally. There are literally thousands of window extrusions, so a hard and fast way of fix is impossible to calculate. This decision has to be made by the person installing.

Face fix: This type of fixing is when their is no recessed area provided for a fly screen, and the screen is simply fitted to the face of the window by drilling through the frame of the window surround, and screwing or riveting directly to the face of the window outer sill and surround. Great care must be given to not interfere with the operation of the window's action, eg. window spirals etc.

To measure for a recess fix is difficult to access, because of the many variations in styles. One simple method is to remeasure the existing fly screen if it is a good fit, and a fix can be obtained. If this option is not available than you must be mindful of being able to fit into the recess and obtain a fix, whilst covering the window. Remember. Window grilles are not flexible. Fly screens are.

In most cases it is best to face fix if recess is difficult. Then you would simply measure where you would like the grille to fix.

REMEMBER PROVIDE US WITH MAKE SIZES.

  1. What colours do you have as standard?
  2. Seconline's security screens are available in 18 standard colours. Refer to Product Details for our full colour chart.
  3. Can I have another colour if I am happy to pay extra?
  4. Yes. Please email with sizes and quantities to info@seconline.com.au and we will provide a quote.



YOU MUST MAKE YOUR OWN DEDUCTIONS - See the DIY Info Centre

 The sizes you provide will be the exact size we make your fly screen; if you are unsure please ask 1300 735 405.





SHIPPING

Once your order is custom made to your specifications it is then packaged for shipment direct to your requested shipping address via Regional Road Express. Once dispatched you will be sent a connote number; see our Terms and Conditions page for estimated transit times.

From the time you place the order your item will be dispatched from our workshop within 10 to 15 working days*. Expected delivery time from date of dispatch is five to ten working days, any delays due to Regional Road Express delivery will be communicated to you by our staff.

If you encounter any issues or have any questions during the ordering process please phone us on 1300 735 405, we are always happy to help.

* Pending availability of stock (Seconline will advise of any stock shortages that may extend the manufacturing time).
